MoTeC Appendices 73

Network Switches and Cables

The C185 must be connected to the network via a network switch.

All MoTeC's PC connection cables (see PC Connection) are Ethernet

crossover cables, that allow direct connection to a PC and are compatible with

network switches that support auto cable sensing (sometimes called “Auto-

MDI/MDI-X” or “Universal Cable Recognition”)

If the network switch does not support crossover cables MoTeC recommends

upgrading the network switch rather than having two types of cables, which

may cause confusion.
