MoTeC Appendices 41

Appendices

Specifications

Specifications listed as optional are available as upgrades to customise and

grow your system. These additional features are activated through a simple

password acquired from MoTeC, at any time when you need it. An overview

of the upgrades can be found in C185 Upgrades.

Logging

• 250 MB standard logging memory (500 MB optional)

• Logging rates up to 1000 samples per second

• Fast Ethernet download

Display

• Type: Colour TFT LCD, anti-reflective

• Resolution: 800 x 480, anti-aliased graphics

• Layouts: selectable fixed layouts, user programmable layouts available in

future releases

• 48 user-defined, scrollable message lines with programmable overrides

• 3 programmable modes with customisable labels

Inputs

• 10 (20 with I/O upgrade*) analogue voltage inputs:

- 4 (8*) x 0 to 5.46 V, 1.33 mV resolution

- 6 (12*) x 0 to 15.0 V, 3.66 mV resolution

• 4 (8 with I/O upgrade) analogue temperature inputs

- 0 to 15 V, 3.66 mV resolution

• 4 x Digital inputs

• 4 x Speed inputs with voltage measuring capability

• 2 x Switched inputs

• Compatible with VIM/SVIM input expanders

Outputs

• 6 x PWM, digital or switched outputs (8 optional)

• 1.0 Amp max, current limited and thermal overload protected

• Compatible with up to 2 E888/E816 input/output expanders
