MoTeC Appendices 69

256 BAD CONFIG Configuration mismatch between C185

and device. Resend the configuration.

512 NO DATA VIMCOM packets have not been found.

Either there is a wiring fault or C185

Connections is setup incorrectly.

2048 WRONG DATA VIMCOM packet has bad length.

4096 BUS WARNING More than 96 errors have occurred on

the CAN bus. Check wiring and

termination resistors. The CAN bus may

still be operational.

8192 BUS OFF More than 255 errors have occurred on

the CAN bus. CAN communications is

suspended when this error occurs.

Check wiring, termination resistors and

the CAN baud rate. Also check that CAN

HI and CAN LO are correct (not

swapped).

VIMCOM Device Errors.

These error codes are sent once by the VIMCOM device on resuming data

transmission and therefore indicate why data was previously not being

transmitted.

4097 STARTUP Device has restarted (normally due to

power up) Data is not sent until sync is

achieved.

4098 HALT Data not sent due to deliberate halt. For

example configuration or firmware being

sent.

4099 OVERRUN Data not sent due to transmit buffer

overrun (possibly due to CAN bus too

busy)

4100 SYNC TIMEOUT Data not sent due to C185 sync

message timeout (sync not received

from C185)

4101 CAN ERROR Data not sent due to error on CAN bus

4102 SYNC

EXCEEDED

Data not sent due to excessive sync

error (synchronisation too far out)
